Construction of Water Distribution Network Nizwa

Scope of Work:

• Zone 1 & 2 Niabat Birkat Al Mooz 1 & 2 and Tawi Al Nusf areas. Approximate length of DI pipeline dia 300 mm is 3 km & HDPE 51 km dia from 125 up to 250 mm.
• Zone 3 Nizwa University and Karsha Industrial Area. The approximate length of DI pipeline dia from 300 up to 600 mm is 9 km & HDPE 31 km dia from 125 up to 315 mm.
• Zone 5 Hail Firq, Hai Al Turath South, and Hai Al Turath North. The approximate length of DI pipeline dia 300 and 400 mm is 6 km & HDPE 66 km dia from 125 up to 250 mm.
• Zone 7 Nizwa Industrial Area, Ridat Al Busaid and Khumailah 2. The approximate length of DI pipeline dia 300 and 400 mm is 7 km & HDPE 44 km dia from 125 up to 315 mm.
• Zone 9 Jahfan West Plan Extension, Alain Extension and Ghaf Al Shaik. The approximate length of DI pipeline dia from 300 up to 500 mm is 7 km & HDPE 28 km dia from 125 up to 200 mm.
• Zone 10 Wadi Samit Extension and Qumah. The approximate length of the DI pipeline is 2 km dia 200 and 300 mm & HDPE 24 km dia from 125 up to 315 mm.
• Zone 11 Tanuf Village and Al Sad Plan. Approximate length of DI pipeline dia 300 up to 500 mm is 5 km & HDPE 47 km dia from 125 up to 250 mm. Construction of water distribution network for a new planned area within this zone might be canceled during the construction stage. Approximate length of DI pipeline dia 300 mm is 2.5 km & HDPE 9.5 km dia from 125 up to 250 mm.

Water distribution network Total length ( DI 300, 400, 500 & 600mm dia = 41.5 Kms / HDPE 125, 200, 250 & 315mm dia =  300.5 kms) = 342  Kms
